MPA1-MIX-NET-V-R

MPA1-MIX-NET-V-R

mpa1-mix-net-v-r-front-and-back-award

The powerful and intuitive MPA1-MIX-NET provides ‘at a glance’ multi-channel audio monitoring and mixing for ST 2110 AoIP networks, with ST 2022-7 and NMOS IS-04/05 support. With 8 dedicated rotary controls, users can quickly create their preferred monitoring mix available from internal speakers, headphone jack, and line outputs. From the total of 128 audio channels available, up to 16 different monitoring mixes can be created and instantly recalled.

Features

  • Front panel display of audio levels, complete with pan/balance information and 8 dedicated rotary controls for source level adjustment
  • 64 channels of AoIP (ST 2110-30, AES67 or RAVENNA) connectivity through dual 1G Ethernet connections supporting ST 2022-7 class B
  • Support for NMOS IS-04, IS-05 (in-band) and SNMP control (out-of-band) for integration with TSL control and leading third-party systems
  • SFP slot for optional 64-channel MADI input (fibre or copper-based) allows simultaneous monitoring of multiple signal formats in hybrid environments
  • Acoustically tuned internal loudspeakers, plus headphone and 2 line-level balanced analogue outputs
  • Up to 8 independent mixes provide instant recall of routing configurations, providing maximum coverage of input sources when required
  • The web interface provides quick and simple control and configuration of all key parameters from any remote location
  • Compact 1RU form factor with a unit depth of only 100mm

Specifications

  • Support for ST 2110-30 Level A, B and C (1ms and 125μs packet time, stream size up to 64 channels)
  • 64 channels of AoIP connectivity through 2 x 1G Ethernet connections
  • Support for 31 AoIP input streams
  • Support for NMOS IS-04 and IS-05
  • Support for ST 2022-7 packet redundancy to Class B
  • Optional support for 64 MADI channels via SFP
  • 16-channel simultaneous display
  • Single 2.4″ display
  • 1.4kg, 1RU height, 100mm depth
  • 85- 264v 50/60Hz mains input on IEC connection
  • 1 x Ethernet connection allowing monitoring and control via a web browser
  • 1 x front panel USB connector for system updates
